KONSAN MEGA FUSING PRESS (MP1000)
TECHNICAL DATA
|
|
19 kW |
|
Fusing Width |
98.5 cm |
|
Max. Temperature |
230 oC |
|
Pressure |
8 kg/cm2 |
|
Max. Belt Speed |
14 m/min |
|
Fusing Time |
5-40 sec. |
|
Machine Width |
142 cm |
|
Machine Length |
420 cm |
|
Machine Height |
120 cm |
|
Machine Weight |
660 Kg |
|
ELECTRICAL DATA |
|
|
380V. 50Hz. |
7000 Watt |
