KONSAN MEGA FUSING PRESS (MP1400)
TECHNICAL DATA
|
|
27 kW |
|
Fusing Width |
138.5 cm |
|
Max. Temperature |
230 oC |
|
Pressure |
8 kg/cm2 |
|
Max. Belt Speed |
14 m/min |
|
Fusing Time |
3-40 sec. |
|
Machine Width |
182 cm |
|
Machine Length |
420 cm |
|
Machine Height |
120 cm |
|
Machine Weight |
930 Kg |
|
ELECTRICAL DATA |
|
|
380V. 50Hz. |
18 kW |
